MHC properties(Moly Hafnium Carbon)

MHC alloy (molybdenum hafnium carbon) characteristics as followed :

Product Number A L W Standard diameter D1 x D2 (tolerance H8)Min D1 Standard diameter D1 x D2 (tolerance H8) Max D2 M
MHC-27C 27 11 35 5 10 M3
MHC-35C 35 12 38 6 14 M3
MHC-40C 40 15 48 8 16 M4
MHC-45C 45 15 48 10 19 M4
MHC-50C 50 20 62 12 22 M5
MHC-57C 57 20 62 12 25 M5
MHC-68C 68 24 74 14 32 M6
MHC-82C 82 30 98 19 35 M8
MHC-95C 95 30 98 22 45 M8

mhcmhcmhc

Following is a comparison of several molybdenum alloy:

Alloy

Nominal Composition (wt%)

Applications

Pure Molybdenum
TZM
MHC
Mo—W
Mo—Re
Mo—La

99.95Mo
0.5Ti,O.08Zr,0.03C
1-.5Hf,0.03-.05C
10-0W
41-7.5Re
0.5—1.5La(State was nearly La2O3)

Vacuum furnaces, glass melting, electronic devices, heat sink
Thermal processing tools, stoves installed appliances
Hot work tool
Molten zinc treatment, sputtering target
Traveling wave tubes, rocket boosters
Sintering boat

If you have any interest in our MHC alloy(molybdenum hafnium carbon) or other molybdenum alloy products, please feel free to contact us by email: sales@chinatungsten.com,sales@xiamentungsten.com or by telephone:86 592 512 9696.
