ZHMR Performance Test Methods

ZHMR Alloy(Zirconium Hafnium Molybdenum Rare Earth Alloy) Performance Test Methods As Follows:zhmr alloy

① Room and high temperature tensile test

Non-standard tensile specimen (Ø3 × 60mm), in CJS5 vacuum instantaneous tensile test machine at the face experiment process to ensure the vacuum of not less than 5 × 10-2Pa, sample holding time of 5min.

② Scanning

Alloy microstructure on ZHMR alloy surface (light corrosion) scanning analysis, with the spectrometer on the tensile dimples second phase particles in semi-quantitative analysis.

③ Transmission Analysis

H-800 transmission electron microscope with a metal thin film morphology structure analysis samples, voltage of 150kV.

④ Phase analysis

Physical and chemical methods using electrolytic extraction of molybdenum alloys second phase, the phase will be taken to make X-ray diffraction analysis phase composition set

⑤ Auger analysis

Scanning Auger with PHI595 significant emblem of the probe, the grain boundaries of the alloy element analysis for analysis.

If you have any interest in our ZHMR alloy(Zirconium Hafnium Molybdenum Rare Earth Alloy) or other molybdenum alloy products, please feel free to contact us by email:, or by telephone:86 592 512 9696.
