Yttria Content ImpactOn ZHMR Alloy(Zirconium Hafnium Molybdenum Rare Earth Alloy) High Performance As Follows:
By the following table to study yttria content on ZHMR high performance alloys.
No. |
Mo | ZrH2 | HfH2 | C | Y2O3 |
1 |
97.8 |
0.5 |
1.5 |
0.19 |
0 |
2 |
97.3 |
0.5 |
1.5 |
0.19 |
0.5 |
3 |
97 |
0.5 |
1.5 |
0.19 |
0.8 |
4 |
96.8 |
0.5 |
1.5 |
0.19 |
1 |
5 |
96.6 |
0.5 |
1.5 |
0.19 |
1.2 |
6 |
96.3 |
0.5 |
1.5 |
0.19 |
1.5 |
The six kinds of rare earth oxide additive amount of yttria ZHMR alloys at 800 ℃, 1000 ℃, 1200 ℃, 1400 ℃ the high temperature tensile strength and elongation of the test showed that:
At 800 ~ 1000 ℃, ZHMR alloy strength has increased significantly, and in 1.0% Y2O3, the peak intensity of the basic, but more than 1200 ℃, the strengthening effect is not obvious. ZHMR3 with increasing temperature, high temperature strength decreased much more than ZHMR6 ease, while PM-ZMR1 of σb-T relations, though more moderate, but in the 800 ~ 1000 ℃ when the high temperature strength is significantly lower. Plus yttrium oxide molybdenum alloy compared with ZHMR1 has greatly improved elongation at 100 ~ 1200 ℃ within, ξ increased from 20% to 35%.
