What Is ZHMR Alloy (Zirconium Hafnium Moly Rare Earth)?

zhmr alloyZHMR alloy(Zirconium Hafnium Moly Rare Earth) is ZHM-based alloys, in which to add the right amount of rare earth oxide of yttrium oxide (Y2O3) to form an alloy.

Molybdenum alloy development from Mo-0.5Ti, TZM to TZC in the pursuit of high-temperature strength, low brittle ductile transition temperature and good plasticity. In recent years, foreign countries began to study the MHC, ZHM TZM and TZC off than a step forward. In addition, many of the rare earth oxides of yttrium oxide (Y2O3) highest melting point of 2410 ℃.

U.S. NASA60 years has done molybdenum alloys of rare earth Y in the application, then the method used for the smelting of Mo and Y together, the results show that Mo was added 0.8% Y, the casting plastic brittle transition temperature (DBTT) dropped 200 ℃, and the alloy has good processing properties, Y, and Mo in the oxygen combined into yttrium oxide as dispersed particles.

ZHMR alloy(Zirconium Hafnium Molybdenum Rare Earth)Preparation

① Material
Experimental materials used for the FMo-1 purity molybdenum powder, commercially pure zirconium hydride powder, industrial oxygen combined chemically pure yttrium powder and toner. Mo powder having an average particle size of 5.9μm, HfH2 yttria is 2.48μm to 1.6μm

② Proportioning and mixing

Mo   ZrH2 HfH2 Y2O3
96.8 0.5 1.5 0.19 1

Weighed according to the proportion of the table, and then mix in the mixing tank, mixing time was 24h.

③ Forming and sintering method
The good material mixed into pouches, in calm press, using 200MPa pressure molding. Forming compacts will burn first, and then it was heated to 2050 ℃, holding time is 2h, sintering atmosphere of hydrogen can be.

If you have any interest in our ZHMR alloy(Zirconium Hafnium Molybdenum Rare Earth Alloy) or other molybdenum alloy products, please feel free to contact us by email: sales@chinatungsten.com,sales@xiamentungsten.com or by telephone:86 592 512 9696.
